	Crankshaft: The Crankshaft of our machine is made from SG Iron. To ensure long life, we have done grinding process on it. The crankshaft is connected to the drive which may be an electric motor, turbine, or a diesel engine. As the crankshaft rotates it, in turn, make the connecting rod to move with it thus making the piston to reciprocate.
	Connecting Rod: The Connecting Rod is made with forged/Cast Iron. It indicates heavy duty and long lasting life. The connecting rod connects the piston and the crankshaft.
	Piston: The piston is made from C.I./Aluminium. The piston moves inside the cylinder wall or the linear, reciprocating up and down
	Piston Ring: We are using M Type Piston ring. Piston Ring can ensure high mechanical and thermal loads. Our Compressor Piston Ring is designed in such a way that they meet international quality standards.
	Cylinder: The cylinder is Shell Moulded for robust working. The cylinder head consists of pockets of holding the intake/suction and delivery valves.The filter is usually mounted onto the cylinder head allowing filtered air to enter compressor unit.
	Tube: The tube is made of copper with brass elbows. It is rust proof.



Helps you to find your goal

Sr. No.	Model	Piston ( CFM)	Max. Working Presure (kg.)	No Of Piston	Tank Size (Inch)	Tank Capacity (Liter)	Motor (HP)	Price (Rs)
1	ACT 34	9.79	12.30	2	18 x 42	175	3	39000
2	ACT 34A	9.79	12.30	2	18 x 45	200	3	41000
3	ACT 42	17.30	12.30	2	18 x 48	200	5	46000
4	ACT 42A	17.30	12.30	2	18 x 58	240	5	49000
5	ACT 53	29.80	12.30	2	18 x 58	240	7.5	62000
6	ACT 2345	36.35	12.30	2	20 x 60	300	10	84000
7	ACT 21T2	44.00	12.30	2	20 x 60	300	12.5	105000
8	ACT 6900	62.20	12.30	3	20 x 60	300	15	142000

Innovation with a Purpose

Why Choose us?

We welcome the recommendations and demands of our clients to serve them in best possible manner. Our unique client servicing makes us the choice of our clients all over. Rely on us for:

• Strong vendor base
• Highly reliable product range
• Moderate pricing policy
• Superior quality products
• Ethical business practices and transparent dealings
• Standardized packaging & delivery system

Lead us to serve more

STANDARD ACCESSORIES:

• Air & Drain Coke
• Non-Return Valve
• Motor RaiL Set
• Motor Pulley
• Pressure Gauge
• Belt Guard
• Automatic Cut-off Pressure Switch

EXTRA ACCESSORIES:

• Electric Motor
• Motor Starter
• V-Belt
• Oil
• Air Dryer
• FRL

We are here to Help you

1. Can I store more air in a tank at higher air pressure?
Yes, but it is not recommended.

2. Can I use PVC piping for my discharge air piping?
Yes

3. How often should we change oil?
If your use is 10 hours per day, You should change it every 2 months.

4. Will my compressor run on a generator?
Yes

5. What type of oil should I use in my air compressor?
ENCLO 150 Grade Oil
